FiberHome HG6543C User Manual

3 Web Configuration Guide
u Ping test: Test whether the router is normally connected with the target host or
another device.
u Traceroute test: Check the condition of the route from the router to the target
host.
1. Select Application in the navigation bar and select Diagnosis→Diagnosis in
the left link bar to open the network diagnosis page, as shown in Figure 3-45.
Figure 3-45 Network Diagnosis
2. Enter the destination IP address to be tested in the Destination Address box,
and click Ping or Traceroute to test. The test result will be displayed in the
lower text box.
3.5.7.23.5.7.2 Nat Session
Click Application and select Diagnosis→Nat Session at the left side to open the
Nat session page and query the mappings between the inner / outer network IP
address of NAT and the ports, as shown in Figure 3-46.
Version: A
73
