Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM L850-GL Series Hardware Guide Page 11 of 59
Interface
Antenna Connector
WWAN Main Antenna ×1
WWAN Diversity Antenna ×1
Function Interface
USIM 3V/1.8V
PCIe Gen1 ×1
USB 2.0
USB 3.1 Gen1 (Base on Android/Linux)
W_Disable#
BodySAR
LED
Clock
Tunable antenna
I2S (Reserved)
I2C (Reserved)
Software
Protocol Stack
IPV4/IPV6
AT commands 3GPP TS 27.007 and 27.005
Firmware update PCIe
Other feature
Multiple carrier
Windows MBIM support
Windows update
Note:
When temperature goes beyond normal operating temperature range of -10°C~+55°C, RF
performance of module may be slightly off 3GPP specifications. For normal operating
temperature, LTE FDD Band 4 and 13 can support temperature ranging from -20°C to +60°C.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fibocom L850-GL Series and is the answer not in the manual?

Fibocom L850-GL Series Specifications

General IconGeneral
CategoryGSM/GPRS Modules
ModelL850-GL
Form FactorM.2
Operating Temperature-10°C to +55°C
Storage Temperature-40°C to +85°C
GSM Bands850/900/1800/1900MHz
GNSSGPS, GLONASS, BeiDou, Galileo
InterfaceUSB 2.0, UART, PCM, I2C, GPIO
Operating Voltage3.135V to 4.4V
LTE FDDB1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B25, B26, B28, B29, B30, B66
LTE TDDB38/B39/B40/B41
WCDMAB1, B2, B4, B5, B8
AT Command Set3GPP TS 27.007
CertificationsCE, FCC, GCF, PTCRB
