FIBOCOM L850-GL Series Hardware Guide Page 52 of 59

4.6 Antenna Design

The L850 module provides main and diversity antenna interfaces, and the antenna design requirements

are shown in the following table:

L850 Module Main Antenna Requirements

Frequency range The most proper antenna to adapt the frequencies should be used.

Bandwidth(WCDMA)

WCDMA band 1(2100): 250 MHz

WCDMA band 2(1900): 140 MHz

WCDMA band 4(1700): 445 MHz

WCDMA band 5(850): 70 MHz

WCDMA band 8(900): 80 MHz

Bandwidth(LTE)

LTE band 1(2100): 250 MHz

LTE band 2(1900): 140 MHz

LTE Band 3(1800): 170 MHz

LTE band 4(1700): 445 MHz

LTE band 5(850): 70 MHz

LTE band 7(2600): 190 MHz

LTE Band 8(900): 80 MHz

LTE Band 11(1500): 68 MHz

LTE Band 12(700): 47 MHz

LTE Band 13(700): 41 MHz

LTE Band 17(700): 42 MHz

LTE Band 18(800): 80 MHz

LTE Band 19(800): 80 MHz

LTE band 20(800): 71 MHz

LTE band 21(1500): 63 MHz

LTE band 26(850): 80 MHz

LTE band 28(700): 100 MHz

LTE band 29(700): 12 MHz

LTE band 30(2300): 55 MHz

LTE band 66(1700): 490 MHz

LTE band 38(2600): 50 MHz

LTE Band 39(1900): 40 MHz
