Fibocom L850-GL Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM L850-GL Series Hardware Guide Page 51 of 59
Mode Band
3GPP Requirement
(dBm)
Rx Sensitivity (dBm)
Typical
Note
Band 26 -93.8 -103 10MHz Bandwidth
Band 28 -94.8 -103 10MHz Bandwidth
Band 29 -93.3 -101 10MHz Bandwidth
Band 30 -95.3 -100.5 10MHz Bandwidth
Band 66 -95.8 -101 10MHz Bandwidth
LTE TDD
Band 38 -96.3 -101 10MHz Bandwidth
Band 39 -96.3 -101.5 10MHz Bandwidth
Band 40 -96.3 -100.5 10MHz Bandwidth
Band 41 -94.3 -100 10MHz Bandwidth
Note:
The above values are measured for the dual antennas situation (Main+Diversity). For single main
antenna (without Diversity), the sensitivity will drop around 3dBm for each band of LTE.
4.5 GNSS
L850 module supports GNSS with D/G antenna, including GPS/GLONASS/BDS. GNSS feature and
performance are as below table.
Description Condition
Test Result
MAX Typical
Current
GPS fixing 140mA@-130dBm 120mA@-130dBm
GPS tracking 140mA@-130dBm 120mA@-130dBm
GPS Sleep 3.5 mA@-130dBm 2.0mA@-130dBm
TTFF
Cold start 50s@-130dBm 39s@-130dBm
Warm start 45s@-130dBm 33s@-130dBm
Hot Start 3s@-130dBm 2s@-130dBm
Sensitivity
Tracking -156dBm -160dBm
Acquisition -144dBm -149dBm
Note:
Please note that GNSS current is tested with RF disabled.

Fibocom L850-GL Series Specifications

General

Category	GSM/GPRS Modules
Model	L850-GL
Form Factor	M.2
Operating Temperature	-10°C to +55°C
Storage Temperature	-40°C to +85°C
GSM Bands	850/900/1800/1900MHz
GNSS	GPS, GLONASS, BeiDou, Galileo
Interface	USB 2.0, UART, PCM, I2C, GPIO
Operating Voltage	3.135V to 4.4V
LTE FDD	B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B25, B26, B28, B29, B30, B66
LTE TDD	B38/B39/B40/B41
WCDMA	B1, B2, B4, B5, B8
AT Command Set	3GPP TS 27.007
Certifications	CE, FCC, GCF, PTCRB
