2 Overview
2.1 Introduction
L850 is a highly integrated 4G WWAN module which uses M.2 form factor interface. It supports LTE
FDD/LTE TDD/WCDMA systems and can be applied to most cellular networks of mobile carrier in the
world.
2.2 Specification
Specification
Operating Band
L850-GL-00, L850-GL-01,
L850-GL-02, L850-GL-03,
L850-GL-05, L850-GL-10
series (except L850-GL-
10-06)
L850-GL-12
L850-GL-20
LTE FDD: Band 1, 2, 3, 4, 5, 7, 8, 11, 12, 13, 17, 18,
19, 20, 21, 26, 28, 29, 30, 66
LTE TDD: Band 38, 39, 40, 41
WCDMA/HSPA+: Band 1, 2, 4, 5, 8
L850-GL-10-06
LTE FDD: Band 2, 4, 5, 13
GNSS
Support GPS, GLONASS, BDS
LTE
3GPP Release 11
UMTS
3GPP Release 8
Data Transmission
LTE FDD
450Mbps DL(Cat 9)/50Mbps UL(Cat 4)
LTE TDD
347Mbps DL(Cat 9)/30Mbps UL(Cat 4)
When LTE TDD achieves maximum DL rate, its UL
rate can reach 10Mbps only
UMTS/HSPA+
UMTS: 384 kbps DL/384 kbps UL
DC-HSPA+: 42Mbps DL(Cat 24)/5.76Mbps UL(Cat6)
Power Supply DC 3.135V~4.4V, Typical 3.3V
Temperature
Normal operating temperature: -10°C~+55°C
Extended operating temperature: -20°C~+65°C
Storage temperature: -40°C~+85°C
Physical
characteristics
Interface: M.2 Key-B
Dimension
：
30×42×2.3mm
Weight: About 6.2 g

Fibocom L850-GL Series Specifications

General

Category	GSM/GPRS Modules
Model	L850-GL
Form Factor	M.2
Operating Temperature	-10°C to +55°C
Storage Temperature	-40°C to +85°C
GSM Bands	850/900/1800/1900MHz
GNSS	GPS, GLONASS, BeiDou, Galileo
Interface	USB 2.0, UART, PCM, I2C, GPIO
Operating Voltage	3.135V to 4.4V
LTE FDD	B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B18, B19, B20, B25, B26, B28, B29, B30, B66
LTE TDD	B38/B39/B40/B41
WCDMA	B1, B2, B4, B5, B8
AT Command Set	3GPP TS 27.007
Certifications	CE, FCC, GCF, PTCRB
