Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM L850-GL Series Hardware Guide Page 59 of 59
5.6.2 Tray Size
The pallet size of L850 module is 315×170×6.5mm, as shown in Figure 5-7:
Figure 5-7 Tray size (unit: mm)
ITEM DIM (Unit: mm)
L
315.0±2.0
W 170.0±2.0
H 6.5±0.3
T 0.8±0.1
A 43.0±0.3
B 31.0±0.3
C 79.0±0.2
D 60.0±0.2
E 180.0±0.2
F 60.0±0.2
G 40.0±0.2
