FieldBee toolbox manual v.1.0
○ if your receiver has power level less than 3,7V we strongly recommend to charge it.
● SOC: status of charge - display current power level in % in range of 100%.
● Charger Status:
○ Discharging ( when power source is Battery)
○ Charging ( when power source is External)
○ Charged (when Battery level/SOC has maximum value)
● GNSS Status: current Positioning status:
INVALID- Base station does not display GNSS status as it is for the receiver. INVALID is normal
state for Base station.
● LoRa RSSI ( Received Signal Strength Indication) for base is constant value 20.
● LoRa SNR (Signal-to-Noise Ratio) for base is 0 all the time.
● Wi-Fi Status : display current status for Wi-Fi connection
○ Not_Connected - FieldBee receiver is not connected to any Wi-Fi network
○ Connected - FieldBee receiver is connected to Wi-Fi Network
○ Connected_NTRIP - - FieldBee receiver is connected to NTRIP network via Wi-Fi.
● Wi-Fi RSSI: displays Wi-Fi network power level.
● Version for MCU, GNSS, Wi-Fi display current version for each module.
Radio channel and region
To get RTK correction via radio channel base station and receiver should have the same radio channel and region.
To edit radio channel follow next steps:
A. open Advanced settings
B. open Radio channel
Note: For US, Canada, Australia and New Zealand countries need to apply US region.
For Europe, Africa and South America need to apply EU region.
If you have any difficulties with radio signal reception ( signal is poor, noises or interferences) we recommend to change
radio channel.
● EU channel 9=865.2 Mhz
● EU channel 10=865.6 Mhz
● EU channel 11=866.0 Mhz
● EU channel 12=866.4 Mhz
● EU channel 13=866.8 Mhz
● EU channel 14=867.2 Mhz
● EU channel 15=867.6 Mhz
● EU channel 16=868.0 Mhz
Elevation Mask
Elevation mask adjustment helps to receive more or less satellites with stronger or weaker signal.
Factory setting are 7 degree and 35 dB.
This is optimal parameters for maximum satellites with useful signal.
You may adjust this parameters if you have not horison at base station view. Range is between : for degrees from 5 to 85
