FieldBee toolbox manual v.1.0
for CNR from 0 to 40 dB.
Constellation Mask
Constellation mask adjustment helps to manage satellites constellations which are in use.
To have maximum useful satellites constellation:
choose GPS and GLONASS
tap Save button.
After applying configurations: GPS and GLONASS should be On.
RTK Mode parameters
Base station can work in Survey and Static mode.
Survey mode provide relative accuracy for Navigation and free choosing of base station position (not as static).
To apply Survey mode:
open Main menu
go to Base station position
apply Survey mode.
If there is any difficulties with applying:
go to Advanced settings;
open RTK Mode parameters;
choose Survey;
input survey length 60 and standard deviation 60
tap the Apply button.
Static Mode - see Chapter Static mode.
Wi-Fi settings
Wi-Fi settings display full info about FieldBee connection to NTRIP server.
Next lines should stay constantly:
Caster IP: 104.199.73.93
Caster port:60008
Feeder IP: 104.199.73.93
Feeder port:60008
Settings server IP: 104.199.73.93
Settings server port: 64004
Caster mountpoint - serial number of your Base station( 8 symbols, e.g. CBC91111)
Caster login - first 4 symbols of Base station serial number. Example: CBC9
Caster password - last 4 symbols of Base station serial number. Example: 1111
Feeder mountpoint for your Base station
Feeder login : first 4 symbols of Base station serial number
Feeder password: last 4 symbols of Base station serial number
Firmware update
Contact your dealer or our support to know does your FieldBee need to be updated.
