FieldBee RTK - Receiver Adjustment and Modes

FieldBee toolbox manual v.1.0
Profiles
Profiles provide possibility to set up base as antenna with specific parameters for radio channel (EU or other World).
Reset
You can reset FieldBee modules separately without manual restarting antenna.
If you have no physical chance to restart antenna ( FieldBee is located at the roof or other place without possibility to
restart it manually) - Choose MCU and apply to restart FieldBee.
If there are any problems with satellites reception - choose GPS2 module and apply to restart GPS module.
Radio module and Wi-Fi module restart only by applying MCU restart.
RTCM settings
If you need to set up your Base station for transmitting correction in RTCM format :
Enable RTCM
Add mark to message 1005, message 1087, message 1077 and message 1107
Binary Config
Base station should have 1Hz update rate.
Time measurement : false
Raw measurement: false
SV CH status: false
RCV status: true
Ext.Raw measurement : true
GPS: true
GLONASS: true
Galileo: false
Beidou: false
FieldBee GNSS receiver adjustment
Switch RTK mode
We recommend to limit FieldBee GNSS Receiver accuracy to Float RTK if RTK correction is not stable (e.g. when the
base station is more than 10 km away).
To switch RTK mode:
1) turn fieldbee receiver on.
2) open fieldbee toolbox app
3) choose fieldbee (fig.1.1)
4) tap fieldbee serial number to continue setup (fig.1.2)
5) tap Switch RTK mode (fig.8.1)
6) choose mode that you want to work with (fig.8.2)
7) tap Save button (fig.8.3)
Restart Fieldbee receiver and wait for correction signal.
