FieldBee toolbox manual v.1.0
○ Connected - FieldBee receiver is connected to Wi-Fi Network
○ Connected_NTRIP - - FieldBee receiver is connected to NTRIP network via Wi-Fi.
● Wi-Fi RSSI: displays Wi-Fi network power level.
● Fix Status : display current satellites amount is use, GNSS Status and RMS (value for accuracy in cm)
● Version for MCU, GNSS, Wi-Fi display current version for each module.
Radio Channel and region
Check Radio Channel settings for Base, following the link Radio Channel
Elevation Mask
Elevation mask adjustment helps to receive more or less satellites with stronger or weaker signal.
Factory setting are 7 degree and 35 dB.
This is optimal parameters for maximum satellites with useful signal.
You may adjust this parameters if you have not horison at base station view. Range is between : for degrees from 5 to 85
for CNR from 0 to 40 dB.
Constellation Mask
Constellation mask adjustment helps to manage satellites constellations which are in use.
To have maximum useful satellites constellation:
choose GPS and GLONASS
tap Save button.
After applying configurations: GPS and GLONASS should be On.
RTK Mode Parameters
RTK Mode parameter for receiver you can edit from the Switch RTK mode screen.
Wi-Fi settings
Wi-Fi settings display full info about FieldBee connection to NTRIP server.
But next lines should stay constantly:
Caster IP: 104.199.73.93
Caster port:60008
Settings server IP: 104.199.73.93
Settings server port: 64004
Caster mountpoint - serial number of your antenna ( 8 symbols, e.g. CBC91111)
Caster login - first 4 symbols of antenna serial number. Example: CBC9
Caster password - last 4 symbols of antenna serial number. Example: 1111
Feeder Ip, port, mountpoint, login and password depends on the NTRIP network you are using.
If you are using FieldBee base station it will be next configuration:
Feeder IP: 104.199.73.93
Feeder port:60008
Feeder mountpoint for your Base station
Feeder login : first 4 symbols of Base station serial number
