3 Technics
3.1 Master data sheet
Description of machine: Electro-hydraulic column lift equipment to lift vehicles at the
wheels or at the chassis; synchronisation with safety shut-off,
additional safety by mechanical locking device at each column.
Lift type: EHB702V11
Capacity per column: 2,5 t
Load support:
Wheel fork adjustable for wheel sizes 3.50R13 – 14.5R20,
resp.diameter 340 – 1100 mm
Length of fork: 350 mm
Version „Hymer“
Lifting height: 1700 mm (effective)
Lifting-/ lowering time: appr. 90 sec.
Operation:
Up/ Down at every column
Operation modes: Common / Single
Cable connection: Cable connection from column to column, length of cables 10 m.
Power supply cable with plug, 10 m, at master column.
Control: Synchronisation in cycle steps, system deviation max. 3 mm.
Supervision of all operation functions.
Drive: Electro-hydraulic
Motor 0.75 kW per column
Connection: 400 V / 3 Ph+PE / 50 Hz, 16 A
Control voltage: 24 V
Operating pressure
at nominal load:
160 bar
Pressure relief valve adjusted to 165 bar
Weight: 420 kg per column
Protection class: IP 65
Admissible temperature range: -5° bis 50°C
Admissible ground inclination: 1°
Noise level: < 70 dB(A)
Hydraulic oil: HLP ISO-VG 32
Surface treatment: Powder coating
