10.3.2 Spare parts list master column
Pos. Description Quantity Article number
control box
base circuit board 1 GRPL-HGP05-KPL
control circuit board master 1 STPL-HRP071-KPL
control circuit board slave 1 STPL-ERP05-KPL
bridge board 1 STPL-FEIN97BR
LED-circuit board with 5 LED 1 STPL-6LED00KPL-5
F6 Motor protection relay LR2K0308
F2/ F3 fuse M2.5 2 SI2,5MT5x20
F7 fuse M1.6A on control circuit board master 1 SI1,6MT5x20
F8 fuse M6.3A on control circuit board slave 1 SI6,3MT5x20
H1/ H4 LED green 2 67S4600
H2 LED yellow 1 67S4550
H3 LED blue 1 67S4605
H5 LED red flashing 1 LD599ROT
K1M motor contactor 1 LP4K0610BW3
Q1 main switch 1 P1-25/EA/SVB
S1 emergency-stop switch 1 ZB4BT4
S2 START-switch 1 ZB4BW37
S3 selection switch 2 positions 1 ZB4BJ2
S4/ S5 roller limit switch 2 XCMN2102L2
S7 up/down push button with plastic cover 1 ZB4BA9112
T1/ V1 transformer 1 EG15VA150
Y1 solenoid valve NO 24V DC See hydraulics
Y2
solenoid valveNC 24V DC, with emergency lowering
screw
See hydraulics
Y3 solenoid for mechanical lock 1 HT-D 70-N 24VDC
M1 electric motor
interconnect cable grey 10m with plug 1 KAB-706-VERB
plug housing (16 pol.) 1 MHO16L32
plug inset (16 pol.) 1 JCSEM16
socket housing (16 pol) 1 7132516280
socket inset 1 JCSEF16
power supply cable, 4x2.5, 10m with plug 1 KAB-706-ZUL
