6.3 Cable connection
CAUTION
Hazard of damage of connecting cables by inappropriate use.
• Always lock plugs in the sockets.
• Do not pull on the connecting cables or on power supply cable.
• Do not bend or twist connecting cables.
• When rolling up regard minimum bending diameter of 300 mm.
• Before movement of columns always unplug connecting cables, roll them up and
place them on the hooks provided.
• Protect connecting cables from damage.
• Do not drive vehicle over cables.
• When removing the connecting cable pull plug out in a straight line and not at an
angle.
• Always close sockets at columns if no plugs are inserted.
6.4 Load support
CAUTION
Hazard of property damage on vehicle and lift.
• Only lift the vehicle at the wheels specified by the vehicle manufacturer, particu-
larly when lifting vehicles with twin wheel axes or trailing axles.
• When positioning the column to the vehicle observe no overhanging car body
parts such as mirrors will be damaged.
DANGER
Hazard of vehicle to fall by wrong support.
• Observe admissible wheel sizes.
•
Position column exactly to the wheel centre.
DANGER
Hazard of vehicle to fall by wrong support.
• Do not lift vehicles with defective wheels or tyres with insufficient air pressure.
• The fork tines must lie close to the underside of the wheel, so that, should the
tyre lose air, there is no danger of the tyre to slip through.
