Spare parts lists and circuit diagrams
Walter Finkbeiner GmbH
Alte Poststrasse 9/11
72250 Freudenstadt / Germany
www.finkbeiner.eu
î 40 / 56
PB-BA-EHB702-102GB
22.02.2011
Pos. Description Quantity Article number
1 column 1
1.1 cover hydraulic unit 1 7060153002-RAL7015
1.2 Cover limit switch 1 7020141003-S-RAL7015
2 rear wheel jack, complete 1 A032100005-KPL-702
2.1.1 Front wheel 2 7020201010
2.1.2 Bearing front wheel 4 6204-2RS
2.2.2 Flat spring 1 A032126004
2.2.3 Spring 1 D409
3 carriage 1
3.2 axle carriage roller with grease nipple 4 7020323003-KPL
3.3 carriage roller complete with slide bearing 4 7020321003-KPL
3.4 plastic slide guide 6 7020301054-FR
3.5 switch cam 7 7060318002
4 hydraulic cylinder 1 See hydraulics
5 locking device 1
locking latch 1 7020501006
solenoid 1 HT-D 70-N 24VDC
spring 1 VD145DJ
7 roller switch incl. housing complete 1 706070100003-KPL
roller limit cycle switch 2 XCMN2102L2
spring 2 D165A
housing for limit cycle switches 1 706070100007
8 hydraulic power unit 1 See hydraulics
9 control box (see chapter electrics) 1 See electrics
