Program Change - Level One
3.3.4 System Edit
The System Edit function is selected by pressing '3'. The system edit screen appears as shown below for software
releases prior
to P/N 73750. This software does not support the LCD-40 Annunciator.
Use the up and down arrow keys to scroll through the choices for each option and the left and right arrow keys to
move from option to option.
There are eight system function options for software releases prior to P/N 73750. The factory default selections and
user option selections are shown below:
The system edit screen appears as shown below for software P/N 73750 or greater. This software is required to
support the LCD-40 Series Annunciators.
VF=N SI=N AS=N PS=N
CD=N AN=N ST=4 REM=N
FUNCTION DEFAULT SELECTION
VF = Alarm Verification (N)one (Y) 73 seconds
SI = Silence Inhibit (N)one (Y) 60 seconds
1
AS = Autosilence (N)one (Y) 10 minutes
1
PS = Presignal (N)one (Y) 3 minutes with 15 second Acknowledge
1
CD = Bell Code 1 (M)arch Time (N)one = No Coding (steady)
Note: Bell 2 is fixed steady (T) = Temporal
(C) = California
AN = Annunciators (N)one (Z) = 56 Zones
(ZU) = 56 Zones Annunciator with UDACT-F
2
(P) = 198 Points
(PU) = 198 Points Annunciator with UDACT-F
2
ST = SLC loop style (4) = Style 4 (6) = Style 6
REM = Alarm/Trbl Reminder (N)o (Y)es = Sound onboard piezo every 15 seconds
during alarm and every two minutes during
trouble after acknowledge or silence key
has been pressed.
1Requires prior approval of Local Authority Having Jurisdiction.
2When the UDACT-F has a fault, this entry allows the FACP to display 'DACT Trouble' on the LCD display and printer hardcopy. The his-
tory file will also be updated with this information. For zone annunciation, up to 56 zones, use AFM Series Annunciators or LDM Series
Annunciators. For 198 point annunciation, use the LDM Series Annunciators.
V=N I=N A=N P=N C=N
A/U=N L/P=N S=4 R=N
