Document #51003 Rev.E 01/11/02 P/N 51003:E 63
Power Supply Calculations
TABLE A-3:
Filtered Load in Alarm - External Devices Connected to TB2 & TB4 Only
Device Type # of Devices
Alarm Current
(amps)
Total Current
1
(amps)
1. Current limitations of terminals:
TB4, Terminals 1 & 2 = 2.5 amps
TB4, Terminals 3 & 4 = 0.3 amps
TB4, Terminals 5 & 6 = 0.3 amps
TB1 and TB2, any one circuit = 2.5 amps
Total current draw from all terminals cannot exceed 3.6 amps with standard XRM-1 transformer installed (4000TAE
transformer for the MS-9200E); 6.0 amps with both standard XRM-1 transformer (4000TAE for the MS-9200E) and
optional XRM-24 transformer (XRM-24E for the MS-9200E) installed. Note that total current from TB4, Terminals 3
& 4 and 5 & 6 must not exceed 0.600 amps.
Main Circuit Board 1 X 0.168 = 0.168
RTM-8F [ ] one max. X
0.146
2
2. All RTM-8F Relays activated
=
ACM-8RF [ ] X
0.158
3
3. All eight ACM-8RF Relays activated on a single module
=
ACM-16ATF
ACM-32AF
[ ] one max. X
0.056
4
4. All annunciator LEDs on
=
AEM-16ATF
AEM-32AF
[ ] X
0.018
4
=
AFM-16ATF
AFM-32AF
[ ] X
0.056
4
=
AFM-16AF [ ] X
0.065
4
=
411UD [ ] one max. X
0.170
5
5. Maximum 300 mA possible with all four inputs shorted, 411UD communicating, programmer connected and Lamp Test
active
=
UDACT-F [ ] one max. X
0.075
6
6. UDACT-F actively making phone call to Central Station. If the normally open contact is used, current consumption
increases to 100 mA
=
LDM-32F [ ] X
0.056
7
7. LDM-32F with LEDs on
=
LDM-E32F [ ] X 0.018 =
LCD-40 Series [ ] X 0.066 =
4-Wire Smoke Detector [ ] X [ ] =
Power Supervision Relay [ ] X [ ] =
Addressable Devices
maximum draw
for all devices
X0.2= 0.2
Notification Appliances [ ] X [ ] =
Auxiliary Devices Powered
from TB4
[ ] X [ ] =
Sum Column for Alarm Load = amps
8
8. This column must not exceed total system current draw of 6.6 amps
To Next Page
