Software Zones
68
Document #51003 Rev.E 01/11/02 P/N 51003:E
TABLE B-2:
Module Programming Sheet Example
MONITOR/CONTROL MODULE ZONE ASSIGNMENT
Address
Device
Type
Zone
Number
ADJ (5 charact. max)
NOUN (9 charact. max)
Address
Device
Type
Zone
Number
ADJ (5 charact. max)
NOUN (9 charact. max)
01 MMF-300 1 WEST HALL 51
02 MMF-301 2 EAST STAIRWELL 52
03 CMF-300 1, 2, 3 2ND FLOOR 53
04 CMF-300 1 1ST FLOOR 54
05 CMF-300 1 EAST HALL 55
06 CMF-300 2 ELEV. LOBBY 56
07 CMF-300 2 MEZZANINE 57
08 CMF-300 3 3RD FLOOR 58
09 CMF-300 3 MECH. ROOM 59
10 60
11 61
12 62
13 63
14 64
15 65
16 66
17 67
18 68
19 69
20 70
21 71
22 72
23 73
24 74
25 75
26 76
27 77
28 78
29 79
30 80
31 81
32 82
33 83
34 84
35 85
36 86
37 87
38 88
39 89
40 90
41 91
42 92
43 93
44 94
45 95
46 96
47 97
48 98
49 99
