Operating Instructions Supervisory Operation
134 MS-9200UD PN 51906:A 12/10/02
• Second line in display:
✓ <ADJ>; refers to the user programmed adjective descriptor from library list
resident in the control panel or custom entry via PC.
✓ <NOUN>; refers to the user programmed noun descriptor from library list
resident in the control panel or custom entry via PC.
• Third line in display: Z000 indicates the zone programmed to this device which,
in this example, is general alarm Zone 000. Note that a single device can be
programmed to five different zones but only the first zone will be displayed.
• Fourth line in display:
✓ Time; the current time in this example is
10:00A
which represents 10:00 AM
✓ Date; the current month, day and year in this example is
01
for January,
08
for
the 8th day of the month and
01
for the year 2001
✓ Device Address;
1M001
in this example
1
represents SLC Loop,
M
represents
a module and
001
represents device address 001
4.6 Supervisory Operation
Supervisory operation is similar to alarm operation but with the following differences:
• The piezo sounder pulses ½ second On and ½ second Off
• The Supervisory LED flashes ½ second On and ½ second Off
• The LCD displays the status label
Active Supervisory
along with the device
name, type, address, adjective/noun, associated zones and time/date
• Communicate the supervisory condition to the Central Station
• The supervisory relay is activated
• The alarm relay is not
activated
• Silenced alarms are resounded
• Timers are not started
• Store event in history buffer
• Terminate upload or download communications
A typical Supervisory event would be displayed as illustrated in the following:
Note that, like alarms, supervisory signals latch (except when programmed for
supervisory autoresettable) and can be assigned to software zones. Supervisory alarms
do not cause resound as do other alarm conditions. Open circuits in supervisory wiring
are processed by the control panel the same way as other trouble conditions. Refer to
"Alarm Operation" on page 133, for a description of the information displayed on the
control panel LCD.
ACTIVE SUPERVISORY
<ADJ> <NOUN>
Z000
10:00A 010801 1M001
