4.22.13 Service Terminal
Pressing 1 while viewing Read Status Screen #5 will display the following screens:
The Panel ID number is displayed as the first item in Service Terminal Screen #1.
To view the phone number for each Service Terminal, press 2 for Terminal 1 or 3 for
Terminal 2 while viewing Service Terminal Screen #1.
The Ring Count is displayed in Service Terminal Screen #2.
4.22.14 Printer/PC
Pressing 2 while viewing Read Status Screen #5 will display the following screens:
The display will inform the operator as to whether the control panel is configured for a
printer or a PC. In the example above, PR4800 indicates that the panel is configured for
a printer with a baud rate of 4,800.
READ STATUS
1=SERVICE TERMINAL
2=PRINTER/PC
3=PRINT
Read Status Screen #5
SERVICE TERMINAL
PANEL ID
2=TERMINAL 1
3=TERMINAL 2
SERVICE TERMINAL
RING COUNT
Service Terminal Screen #1
Service Terminal Screen #2
PRINTER PC
PRINTER PC PR4800
START BIT
STOP BIT
PRINTER PC
DATA BITS
PARITY
Printer/PC Screen #1
Printer/PC Screen #2
