3.6.9 Option Modules
Options available for the MS-9200UD include ACM Series, Graphic and LCD
annunciators, printer connection for acquiring hardcopy printouts of panel data and PC
(Personal Computer) connection for uploading and downloading panel data.
Pressing 3 while viewing Programming Screen #3 will display the following screen:
Note that PR4800 in the display indicates that a supervised printer, configured for 4800
baud, has been previously programmed into the system.
3.6.9.1 Annunciators/UDACT
3UHVVLQJ

ZKLOHYLHZLQJWKH2SWLRQV6FUHHQZLOOFDXVHWKHFRQWUROSDQHOWRGLVSOD\
WKHIROORZLQJVFUHHQV
$7HUPLQDO0RGHDQQXQFLDWRUDQG$&60RGHDQQXQFLDWRUFDQEHLQVWDOOHGLQWKH
068'V\VWHP7RHQDEOHDQ\RIWKHVHGHYLFHVSUHVVWKHQXPEHU
FRUUHVSRQGLQJWRWKHVHOHFWHGGHYLFHVKRZQLQ$QQXQFLDWRU6FUHHQVRWKDW
<HV

DSSHDUVLQWKHGLVSOD\WRWKHULJKWRIWKHGHYLFH(DFKSUHVVRIWKHFRUUHVSRQGLQJ
QXPEHUNH\ZLOOFDXVHWKHGLVSOD\WRWRJJOHEHWZHHQ
(QDEOHG<HV
DQG
(QDEOHG1R

1RWHV
1.

The LCD-80F is a Terminal Mode annunciator. To enable the MS-9200UD for
LCD-80F operation, program Term Enabled to Yes.
2. The Terminal Mode annunciator (LCD-80F) and the Printer/PC use the same
TB8 terminal block on the MS-9200UD main circuit board. Only one device can
be connected at one time, therefore, programming Term Enabled to Yes will
disable any Printer/PC communications.
PROGRAMMING
1=HISTORY
2=WALKTEST
3=OPTION MODULES
Programming Screen #3
OPTION MODULES
1=ANNUNCIATORS/UDACT
2=ONBOARD DACT
3=PRINTER/PC PR4800
Options Screen
ANNUNCIATOR
1=TERM ENABLED YES
2=ACS ENABLED YES
3=UDACT YES
Annunciator Screen #1
ANNUNCIATOR
1=ACS INSTALLED
Annunciator Screen #2
