SECTION 3
Programming
3.1 Programming Data Entry
Programming can be accomplished using the MS-9200UD keypad or by connecting an
optional standard computer keyboard. The keyboard can be connected to the PS-2
connector J3 on the control panel main circuit board.
The information presented in this section refers to programming the MS-9200UD via
the onboard keypad. If an optional computer keyboard is connected to the MS-9200UD
main circuit board, the following table describes the keyboard keys which correspond
to the onboard keypad keys.
Keypad Keys Computer Keyboard Keys
1st Event Home
CLR Delete
ESC Esc
RECALL Insert
**
##
A - Z A - Z
0 - 9 0 - 9

(on QZ key)
Space bar
——
//
••




ENTER Enter
ACK/STEP F1
SILENCE F2
DRILL F3
RESET F4
