2. General description
The basic control panel has been specifically designed for the interconnection and supervision of
the accessories supplied with the FISAIR Evaporative Humidifiers. The incorporation of the CCB2.0
provides a more accurate, simple and reliable integration for this in air handling units.
The control panel manages all the field components of FISAIR Evaporative Humidifiers:
• Water recirculation pump
• Detector of the minimum and maximum basin water level
• Basin water supply solenoid valve
• Emptying/draining motor-valve in the basin
• UV lamp water treatment system (optional)
• Water conductivity control (optional)
• Modbus TCP/IP (optional)
• Modbus RTU (optional)
• BACnet/IP (optional)
* For the MAXIMUM distance of the conductivity probe, ask FISAIR when
CCB2.0 + Conductivity Control
Figure 1: Examples of installation of CCB2.0 on vertical wall and CCB2.0 integrated in the AHU
