8.7.2. BACnet/IP:
Pay attention to the following screens that the Display shows regarding this type of communication:
❖ BACNET UDP Port: Select the address of the Bacnet UDP Port. By default it is 47808.
❖ Bacnet Device number: Select the BACnet device number. By default it is 1234.
BACnet/ IP Protocol:
• Type: Bacnet/IP over Udp
• Connect the Ethernet cable to the SEF-029 card before starting the Disconnector I1. The
LEDs for connection (yellow) and communication (green) are not currently available.
The default IP address is 10.42.0.100
• The foreign device must be registered as follows:
Remote BBMDIPv4.IPv6 Endpoint = 10.42.0.100:47808
Mapping for BACnet communication protocols:
Write: The following table shows the write function of each communication object:
Object
Description
Writing
SET OnOff Auto*
(Analog_Output:0)=1010
Write position disconnector
switch I1
0→OFF, 1→ON, 2→AUTO(Subject
to interlocking function in J21)
SET DRAIN CONFIG.
(Analog_Output:14)=1064
Write signal configuration
empty
0→Never, 1→Standard, 2→
Conductivity control
SET_LANGUAGE
(Analog_Output:16)=1070
Write Language
0→Spanish 1→English 2→German
3→French
RESET DEF. VALUES
(Analog_Input:14)
Reset to factory default
values
Key required for reset 1997
SET EMERGENCY J20
(Analog_Output:17)
Activates the alarm signal
0→ Alarm Off
1→ Alarm On
* These objects are bidirectional: In addition to working as writing, they show the reading of their
states.
