Fisher ET - Parts Kits; Gasket Kits; Packing Kits

ET Valve
Instruction Manual
Form 5081
June 2002
17
Parts Kits
Gasket Kits
Gasket Kits (includes keys 10, 11, 12, 13, and 51; plus 14 and 20 on some restricted capacity valves)
DESCRIPTION
PART NUMBER
Full Capacity Valves
–198 to 593C
(–325 to 1100F)
1 & 1-1/4 inch
1-1/2 inch (2-inch EAT)
2-inch
2-1/2 inch (3-inch EAT)
3-inch (4-inch EAT)
4-inch (6-inch EAT)
6-inch
8-inch
RGASKETX162
RGASKETX172
RGASKETX182
RGASKETX192
RGASKETX202
RGASKETX212
RGASKETX222
RGASKETX232
Restricted Capacity Valves w/ Metal Seating
1-1/2 x 1-inch (2 x 1-inch EAT)
2 x 1-inch
2-1/2 x 1-1/2 inch (3 x 1-1/2 inch EAT)
3 x 2-inch (4 x 2-inch EAT)
4 x 2-1/2 inch (6 x 2-1/2 inch EAT)
RGASKETX242
RGASKETX252
RGASKETX262
RGASKETX272
RGASKETX282
Packing Kits
Standard Packing Repair Kits (Non Live-Loaded)
Standard Packing Repair Kits (non live-loaded)
Stem Diameter, mm (Inches)
Yoke Boss Diameter, mm (Inches)
9.5 (3/8)
54 (2-1/8)
12.7 (1/2)
71 (2-13/16)
19.1 (3/4)
90 (3-9/16)
PTFE (Contains keys 6, 8, 10, 11, and 12) RPACKX00012 RPACKX00022 RPACKX00032
Double PTFE (Contains keys 6, 8, 11, 12) RPACKX00042 RPACKX00052 RPACKX00062
PTFE/Composition (Contains keys 7, 8, 11, and 12) RPACKX00072 RPACKX00082 RPACKX00092
Single Graphite Ribbon/Filament
(Contains keys 7 [ribbon ring], 7 [filament ring], 8, and 11)
RPACKX00102 RPACKX00112 RPACKX00122
Single Graphite Ribbon/Filament
(Contains keys 7 [ribbon ring], 7 [filament ring])
RPACKX00132 RPACKX00142 RPACKX00152
Double Graphite Ribbon/Filament
(Contains keys 7 [ribbon ring], 7 [filament ring], 8, and 11)
RPACKX00162 RPACKX00172 RPACKX00182
