ET Valve
Instruction Manual
Form 5081
June 2002
36
Key 7* 1-Stage Cavitrol III Valve Plug Stem (Design ET only)
VALVE SIZE,
TRAVEL
ACTUATOR
GROUP (FROM
STEM DIAMETER
316 STAINLESS
17-4PH
VALVE SIZE,
INCHES
mm Inches
GROUP (FROM
PRECEDING
TABLE)
mm Inches
316 STAINLESS
STEEL
STAINLESS
STEEL STEM
1 19, 25 3/4, 1 1 12.7 1/2 1U389035162 1U3890X0062
1-1/2 19, 22 3/4, 7/8 1 12.7 1/2 1U389035162 1U3890X0062
2 26 1-1/8
1
1
12.7
19.1
1/2
3/4
1K586935162
1U226535162
10A8840XC82
1U226535382
2-1/2 38 1-1/2
1
1
12.7
19.1
1/2
3/4
1U230535162
1U230835162
1U2305X0012
1U2308X0082
3 38, 41 1-1/2, 1-5/8
1
1
12.7
19.1
1/2
3/4
1U230535162
1U230835162
1U2305X0012
1U2308X0082
4
51, 54
54
54
2, 2-1/8
2-1/8
2-1/8
1
402
403
19.1
19.1
19.1
3/4
3/4
3/4
1K587735162
1V142235162
1U293835162
1K5877X0022
1V1422X0042
1U2938X0062
4
51, 54 2, 2-1/8
100
101
25.4
25.4
1
1
1U217535162
1K759035162
1U217550372
1K7590X0012
6
51
57
51
57
2
2-1/4
2
2-1/4
100
100
100
100
25.4
25.4
31.8
31.8
1
1
1-1/4
1-1/4
1P847635162
1N704735162
1K415435162
1N920935162
11A3429X252
1N7047X0012
1K415435382
1N9209X0052
51, 57 2, 2-1/4
101
101
25.4
31.8
1
1-1/4
1P405135072
1K775335162
1P4051X0032
1K7753X0012
76, 86 3, 3-3/8
100, 101, 404
100, 101, 404
25.4
31.8
1
1-1/4
10A3282X012
1R489535162
10A3282X012
1R4895X0022
8
86 3-3/8
407
407
25.4
31.8
1
1-1/4
11A3429X012
1U9886X0012
1K7783X0052
1U9886X0152
Key 7* Valve Plug Stem for Bellows Seal Bonnet, 316 Stainless Steel
VALVE SIZE, INCHES STEM DIAMETER STEM LENGTH
Design ET Design EAT mm Inches mm Inches
PART NUMBER
1,
1-1/4, 1-1/2, or 1-1/2 X 1
1, 2, or 2 x 1
9.5
12.7
3/8
1/2
222
286
8-3/4
11-1/4
1R288535162
1R288835162
2, 2-1/2,
2-1/2 X 1-1/2, or 3
3 or 4 12.7 1/2 314 12-3/8 1U389235162
––– 3 x 1-1/2 12.7 1/2 295 11-5/8 1U388935162
2 x 1 or 3 x 2 4 x 2 12.7 1/2 305 12 1U389135162
4 6
12.7
19.1
1/2
3/4
327
387
12-7/8
15-1/4
2R369335072
1K587635162
4 x 2-1/2 6 x 2-1/2
12.7
19.1
1/2
3/4
327
375
12-7/8
14-3/4
2R369335072
1U389435162
6 ––– 19.1 3/4 387 15-1/4 1K587635162
*Recommended spare parts
