Getting to Know Your Dreamer
02
1.Extruder Cable Bunch 2.Filament Guide Tube 3.Y-Axis Guide Rod 4.X-Axis Guide Rod
5.Build Plate 6.Build Platform
7.Bracket
8.LevelingKnob
9.Z-Axis Guide Rod
10.Touch Screen
11.Cooling Fan 12.Spring Presser
13.Turbofan 14.Turbofan Baffle
15.Left Nozzle
18.SD Card Slot
19.USB Input
20.Reset Button
21.Power Switch
22.Power Input
17.Side Panel
22
18 19 20 21
1
3
4
5
6
7
9
10
17
8
2
11
12
13
14
15 16
15.Right Nozzle
