VALET" rocker switch for the bedroom monitor
will be located just below the monitor on the
side
of
the cabinet or on the wall adjacent to the
monitor.
These rocker switches are used to select a
source to be displayed on the monitor(s). The
rocker switch are two way momentary
"ON"
switches, which means that when you push
either side
of
the switch and release it, the
switch will move back to the neutral position.
Pressing the top side
of
the switch will move
you
"up" through the images (one at a time) and
pressing the bottom side
of
the switch will move
you
"down" through the images (one at a time).
TRIPTEKTM KEYPAD
The
TripTekTM
Keypad is a part
of
the
TripTekTM
Motor Coach Trip Computer. The
keypad is located on the
left hand driver panel
and is used to navigate through the screens and
functions
of
the
TripTekTM
Motor Coach Trip
Computer. The
TripTekTM
Keypad consist
of
five keys, "'VIEW", "SCREEN", "RESET", up
"
.....
"
and
a
down"
......
".
Note the "VIEW" key is actually two keys in
one package and has a forward
anow "
~
" and
a return
"
~
"
anow
marking.
To
move forward
or backward through the screens, press the side
of
the "VIEW" key that displays the chosen
direction.
The function
of
some keys will vary depending
on the cun'ent screen and available second
(lower) level screens.
When in the
"CHECK LIST" screen use the "up
"
.....
" or "down "
.....
" keys to step through each
line item
of
the "CHECK LIST" screen.
Use the
"VIEW.
" when
in
the "CHECK
LIST"
screen to move out
of
that screen. Once
out
of
the "CHECK LIST" screen the "VIEW"
key can be used to step through the various
screens. The system will step forward or back-
ward, depending on which side
of
the "VIEW"
key is pressed.
The
"SCREEN" key will change data I picture
Heritage
Information
contrast by changing the text background.
Successive presses on the
"SCREEN" key will
give the following options:
The ability to view a data screen and still see
the rear vision image
and
The ability to view data screen only with
either a dark or light background for greater
contrast.
The
"RESET" key will zero all or part
of
the
data on the
cunent
viewed screen.
The up
"~"
and down
"~"
keys are opera-
tional on the
"TODAY" screen for changing
data otherwise the up
"~"
and down
"~"
keys
are used to select the line item desired. The up
"~"
and down
"~"
keys are used to set the
miles to be traveled on the
"TODAY" screen.
./
NOTE
In a screen that gives you a list
of
items use the up
It
.....
11
and
down
II..,
"
keys
to
point
to
your
selection.
The
'VIEW
~"
is used to select the item
and
the
'VIEW
C
is used to return to the selection screen.
DASH MONITOR
The dash monitor will display the outside cam-
eras images when in the security mode and all
cameras (one at a time) or the Navigation
System or the
TripTekTM
system when in the
drive mode.
The dash monitor has six front panel controls:
Power, Input, Dimmer, Volume, Contrast, and
Bright.
POWER
Depress and release the
"POWER" button to turn the
monitor
"ON", the picture
appears on the monitor and the
POWER indicator lights up
green.
To
turn the monitor "OFF"
(STANDBY condition) depress
and release the
"POWER" but-
ton, the picture un-displays on
04-13
