29
ARPEX 8704 en
Operating instructions 01/2019
6.12 Fitting the plate packs
ARPEX plate packs are packed individually, when delivered. The delivery includes instructions for fitting
ARPEX plate packs in German. Instructions in other languages must be ordered separately.
ARPEX fitting instructions include all the necessary data and instructions for correctly fitting the plate
packs.
The tightening torques for the plate pack bolting should exclusively be taken from the related
actual assembly instructions!
Furthermore all necessary details for alignment of the units to be connected are documented.
Matching of all existing sets of fitting instructions with their series is shown in table 7.
The sets of fitting instructions set out below can be ordered from Flender or on the Internet (see back
cover).
Table 7: Matching of the individual series with their fitting instructions
Series Type Assembly instructions
ARS‐6
with close-fitting screw connection AN 4200
with conical bolting AN 4243
ARP‐6
3-part (e.g. "NAN") with close-fitting screw connection AN 4224
3-part (e.g. "NAN") with conical bolting AN 4256
ARP‐6
5-part (e.g. "MCECM") with close-fitting screw
connection
AN 4228
5-part (e.g. "MCECM") with conical bolting AN 4253
ARC‐6/8/10
Standard version AN 4241
Version with special conical bolting AN 4244
ARF‐6 Standard version AN 4233
ARW‐4/6
with close-fitting screw connection AN 4239
with conical bolting AN 4254
ARH‐8
with close-fitting screw connection AN 4213
with conical bolting AN 4246
