FLUXUS ADM 8027, F801, ADM 8127B 16 Settings
112 UMFLUXUS_F8V4-6-1EN, 2018-10-10
16.2.2 Fluid Pressure
The dependence of the parameters of a fluid on the pressure can be taken into account.
16.2.3 Measuring Point Number
16.2.4 Transducer Distance
16.2.5 Error Value Delay
The error value delay is the time after which an error value will be sent to an output if no valid measured values are avail-
able.
Enter the pipe circumference. The limits for the pipe circumference are calculated on the
basis of the limits for the outer pipe diameter.
During the next scroll through the program branch Parameter, the outer pipe diameter
that corresponds to the entered pipe circumference will be displayed.
Example: 180 mm : π = 57.3 mm
Note! The pipe circumference is only edited temporarily. When the transmitter switches back to the display
of the pipe circumference (internal recalculation), slight rounding errors may occur.
Example: entered pipe circumference: 100 mm
displayed outer pipe diameter: 31.8 mm
When the transmitter switches back to the display of the pipe circumference, 99.9 mm will be dis-
played.
If on is selected, the fluid pressure will be requested in the program branch Parameter.
If off is selected, 1 bar will be used for all calculations.
Note! For documentation purposes, it is useful to enter the fluid pressure, even if the transmitter contains
no pressure-dependent characteristic curves.
Select (1234) if the measuring point is to be identified only by numbers, point and dash.
Select (↑↓← ) if the measuring point is to be designated with ASCII characters.
recommended setting: user
user will be selected if the measuring point is always the same.
auto can be selected if the measuring point changes often.
In the program branch Measuring, the recommended transducer distance will be dis-
played in parentheses, followed by the entered transducer distance if the recommended
and the entered transducer distance are not identical.
During transducer positioning in the program branch Measuring
only the entered transducer distance will be displayed if Transd. Distance = user is
selected and the recommended and the entered transducer distances are identical
only the recommended transducer distance will be displayed if
Transd. Distance
=
auto
is selected.
Select edit to enter an error value delay. Select damping if the damping factor is to be
used as the error value delay.
For further information on the behavior of missing measured values see section 18.1.2 and
18.2.
Pipe Circumfer.
180 mm
Outer Diameter
57.3 mm
Fluid pressure
off >ON<
Meas.Point No.:
(1234) >(↑↓← )<
Transd. Distance
auto >USER<
Transd. Distance?
(50.8) 50.0 mm
Transd. Distance?
50.8 mm
Error-val. delay
damping >EDIT<
