Flexim FLUXUS ADM 8027 User Manual

A Menu Structure FLUXUS ADM 8027, F801, ADM 8127B
UMFLUXUS_F8V4-6-1EN, 2018-10-10 143
Special Funct.\SYSTEM settings\Measuring\Calibration
selection of the measuring channel whose flow parameters are to be defined
This display will only be indicated if the SuperUser mode is activated.
determination of the profile bounds
factory: the default profile bounds will be used
user: the profile bounds can be defined
This display will only be indicated if the SuperUser mode is activated.
Input of the max Reynolds number at which the flow is laminar.
range: 0...25 500 (rounded to hundreds)
0: the default limit of 1 000 will be used
This display will only be indicated if the SuperUser mode is activated and
Profile bounds = user is selected.
Input of the min. Reynolds number at which the flow is turbulent.
range: 0...25 500 (rounded to hundreds)
0: the default limit of 3 000 will be used
This display will only be indicated if the SuperUser mode is activated and
Profile bounds = user is selected.
request if an additional correction of the flow velocity is to be defined
on: the correction data can be defined
off: without correction of the flow velocity
This display will only be indicated if the SuperUser mode is activated.
Input of the slope for the correction formula.
range: -2.000...+2.000
0.0: without correction
This display will only be indicated if the SuperUser mode is activated and
Calibration = onis selected.
Input of the offset.
range: -12.7…+12.7 cm/s
0: without offset
This display will only be indicated if the SuperUser mode is activated and
Calibration = onis selected.
SYSTEM settings\Proc. outputs
selection of the displays for the transmitter outputs setting
selection of the output to be installed
SYSTEM settings\Storing
selection of the displays for the storing of measured values in the data logger
setting of the data logger overflow behavior x
INIT-resis-
tant
Calibrat. data ↕
for Channel A:
A:Profile bounds
factory >USER<
Laminar flow
ifR*< 0
Turbulent flow
if R*> 0
A:Calibration ?
>OFF< on
A:Slope=
1.000
A:Offset=
0.0 cm/s
SYSTEM settings↕
Proc. outputs
Install Output ↕
Current I1
SYSTEM settings↕
Storing
Ringbuffer
off >ON<
