Flexim FLUXUS F706**-A2 Series User Manual

A Menu Structure FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 175
Input of the limit for the temperature difference.
All temperature differences between the supply and return line that are lower
than this value will be set to zero.
range: 0...5.0 °C
0: no temperature-based heat flow cut-off
This display will only be indicated if the SuperUser mode is activated and Ther-
mal low cut = on is selected.
x
Activation of the manual reset of the totalizers.
This display will only be indicated if the SuperUser mode is activated.
x
Activation of the display of the sum of the totalizers.
This display will only be indicated if the SuperUser mode is activated.
x
activation of the display of the last valid measured value
This display will only be indicated if the SuperUser mode is activated.
x
activation of the turbulence mode x
Special Funct.\SYSTEM settings\Measuring\Calibration
selection of the measuring channel for which the flow parameters are to be de-
fined
This display will only be indicated if the SuperUser mode is activated.
definition of the profile bounds
factory: the default profile bounds is used
user: the profile bounds can be defined
This display will only be indicated if the SuperUser mode is activated.
Input of the max. Reynolds number at which the flow is laminar.
range: 0...25 500 (rounded to hundreds)
0: the default value 1 000 is used
This display will only be indicated if the SuperUser mode is activated and Pro-
file bounds = user is selected.
input of the min. Reynolds number at which the flow is turbulent.
range: 0...25 500 (rounded to hundreds)
0: the default value 3 000 is used
This display will only be indicated if the SuperUser mode is activated and Pro-
file bounds = user is selected.
request if an additional correction of the flow velocity is to be defined
on: the correction data can be defined
off: no correction of the flow velocity will be used
This display will only be indicated if the SuperUser mode is activated.
input of the slope for the correction formula.
range: -2.000...+2.000
0: no correction
This display will only be indicated if the SuperUser mode is activated and Cali-
bration = on is selected.
INIT-
resistant
Thermal flow ->0
if |dT|< 0.0 C
3xC clear totals
off >ON<
Show Q
off >ON<
Keep display val
off >ON<
Turbulence mode
off >ON<
Calibrat. data ↕
for Channel A:
A:Profile bounds
factory >USER<
Laminar flow
if R*< 0
Turbulent flow
if R*> 0
A:Calibration ?
>OFF< on
A:Slope=
1.00
