2 – Introduction
A6700sc/A6750sc User’s Manual
7
2 Introduction
2.1 Camera System Components
The A6700sc infrared camera and its accessories are delivered in a box which typically contains the
items below. There may also be additional items that you have ordered such as lenses, software,
CDs, etc.
Description FLIR Part Number
A67xxsc Camera 29350-2xx
Power supply, 24V, 4A 24123-000
AC line cord 24124-000
Gigabit Ethernet Cat-6 cable, 2m length 23700-000
Bayonet mount plug 23901-000
BNC cable 26393-000
ResearchIR Max download/activation card T199013
AUX connector breakout cable [A6750sc only] 29402-500
Laboratory calibration plate 261-0005-00
Water-resistant transit case 24043-000
Documentation CD 24048-050
2.2 System Overview
The A6700sc infrared camera system has been developed by FLIR Advanced Thermal Solutions
(ATS) to meet the needs of the commercial R&D user. The camera makes use of FLIR’s advanced
ISC0403 4-channel readout integrated circuit (ROIC), mated to an Indium Antimonide (InSb) detector
to cover the midwave infrared band. The A6700sc camera utilizes a large format, 640 x 512 array
with 15μm pixel pitch.
The A6700sc is a stand-alone imaging camera that interfaces to host PC using Gigabit Ethernet. An
SDK is available, which makes it possible for the system designer to write their own camera controller
and acquire image data with their own custom application.
To Next Page
