2 – Introduction
A6700sc/A6750sc User’s Manual
8
2.3 Key features of the A6700sc/A6750sc cameras
Fully GEV/GenICam compliant
The image stream protocol is GigE Vision 2.0 compliant and the camera is fully controllable
by GenICam.
Improved Linearity to Zero Well-Fill
Typical direct injection ROIC designs exhibit a non-linear response when the signal drops
below 10% of well-fill. The ISC0403 ROIC provides a linear response even at very low signal
levels. This results in an increased linear dynamic range, much better NUC performance at
low signal levels and makes it easier to perform a user calibration of the camera.
14-Bit Digital Image Data
The A6700sc camera system is built around high performance 14-bit A/D converters,
preserving the full dynamic range of the FPA.
Windowing Capability
Higher frame rates are available by windowing down at the Focal Plane Array (FPA) level.
The A6700sc has three available window sizes with a max frame rate of 480Hz. The
A6750sc has flexible window sizes with frame rates up to 4kHz.
Presets
Up to four presets and their associated parameters such as integration time, frame rate,
window size and window location, are available for instant selection with a single command.
Superframing [A6750sc only]
Up to four presets can be cycled continuously. This can be used in conjunction with the
Dynamic Range Extension (DRX) algorithm to provide a single movie with increased dynamic
range.
Independently Adjustable Frame Rates
Frame rate is user selectable from 0.0015 Hz up to the maximum allowed for the selected
window size.
External Sync
The A6700sc camera provides a SYNC input that can be used to control the camera frame
rate using an external LVCMOS input (can handle 5.5V Max).
External Trigger [A6750sc only]
An external trigger input can be used to signal ResearchIR to start recording or to precisely
start the image stream relative to an external event.
Multiple Video Outputs
The A6700sc camera features multiple independent and simultaneous video:
▫ Digital – Gigabit Ethernet
▫ Analog – Composite video (NTSC or PAL)
Analog Video Color Palettes
The A6700sc camera supports a selection of standard and user-defined color palettes for the
analog video output.
