FLIR A70 Series User Manual

Camera web interface
10
• Visual: The camera displays the visual image captured by the visual camera.
• FSX (Flexible Scene Enhancement): The camera displays the thermal image with en-
hanced image details. This image mode is useful when higher contrast is required, for
example when the camera is used in a surveillance application.
To select the image mode, follow this procedure:
1. On the toolbar and in the Data presentation modes section, click Image mode.
2. Select one of the available image modes.
10.4.5 Colorizing the image
The camera can colorize the image in different ways. You can select different color pa-
lettes or apply color alarms (isotherms).
10.4.5.1 Palette
You can change the palette that the software uses to display the different temperatures
within an image. A different palette can make it easier to analyze the image. The most
suitable palette for a certain application depends on many different factors, such as the
target temperature and emissivity, the ambient temperature, and the distance to the tar-
get. You will need to test different palettes in order to find the one that best suits your
application.
To change the palette, follow this procedure:
1. On the toolbar and in the Data presentation modes, click Palette.
2. Select one of the available palettes.
10.4.5.2 Isotherms
By using color alarms (isotherms), anomalies can easily be discovered in an infrared im-
age. The isotherm command applies a contrasting color to all pixels with a temperature
above, below, or between the set temperature levels.
The camera supports the following isotherms:
• Above
Applies a contrasting color (red) to all pixels with a temperature above the specified
temperature level.
#T810579; r. AB/78918/78918; en-US
25
