A-series
connection
board
12
The
A-series
connection
board
is
an
accessory
that
can
be
used
to
test
functionality
and
digital
connections
to/from
the
camera.
Figure
12.1
A-series
connection
board
For
schematics
and
connection
ex
amples,
see
the
ne
xt
pages.
