FLIR E40 User Manual

Recording video clips
20
20.1 General
You can record non-radiometric video clips in the following image modes:
• Thermal MSX.
• Thermal.
• Picture-in-picture.
• Digital camera.
The video clips can be played back in Microsoft Windows Media Player, but it will not be
possible to retrieve any temperature values from them.
20.2 Procedure: Recording a video clip
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Use the navigation pad to go to Recording mode.
3. Push the navigation pad.
4. Select Video and push the navigation pad.
5. Push the Save button to start the recording. A red icon at the top of the image blinks
during the recording.
6. Push the Save button again to stop the recording.
20.3 Procedure: Playing a video clip
Follow this procedure:
1. Push
to open the image archive.
2. Push the navigation pad up/down or left/right to select the video clip that you want to
play.
3. Push the navigation pad to open the video clip.
4. Push the navigation pad to display a toolbar.
5. On the toolbar, select Play and push the navigation pad.
#T559845; r. AJ/37554/37554; en-US
47

FLIR E40 Specifications

General

Resolution	160 x 120 pixels
Accuracy	±2°C or ±2% of reading
Focus	Manual
Image Storage	SD card
Image Frequency	60 Hz
Digital Camera	3.1 MP
Battery operating time	Approx. 4 hours
Operating Temperature	-15°C to +50°C
Storage Temperature	-40°C to +70°C
Spectral Range	7.5 - 13 µm
Field of View	25° x 19°
Display	3.5 in color LCD
Image Modes	Thermal, Visual, MSX
Measurement Presets	Center Spot, Hot Spot, Cold Spot
File format	JPEG
Battery type	Li-Ion battery
Connectivity	USB, Wi-Fi
Thermal Sensitivity	< 0.07°C @ +30°C (+86°F) / 70 mK
