Changing settings
22
Relative humidity 50%
Atmospheric temperature
+20°C (+69°F)
22.3.2 Save options
22.3.2.1 Preview image before saving
Preview image before saving: This setting defines if a preview image will be displayed
before the image is saved.
22.3.2.2 Add annotation after saving
Add annotation after saving: This setting defines if an annotation tool will be displayed
when the image has been saved. Available options are:
• Save: No annotation tool is displayed.
• Save & add note: The note annotation tool is displayed.
• Save & add table: The table annotation tool is displayed. This setting also allows you
to define the type of table. Available options are Inspection - default, Text field - de-
fault, and SEC. You can also create your own table in FLIR Tools and upload it to the
camera.
• Save & add voice annotation: The voice annotation tool is displayed.
• Save & add any annotation: The annotation tool menu is displayed.
22.3.2.3 Photo as separate JPEG
Photo as separate JPEG: This setting defines if a digital photo will be saved as a sepa-
rate file with a full field of view. If this setting is disabled, the digital photo will be saved
with the same field of view as the infrared image.
22.3.3 Add-on lens
This setting defines which accessory lens has been mounted on the camera. Available
choices are None, FOV X (serial number).
22.3.4 Device settings
22.3.4.1 Set up camera
22.3.4.1.1 Camera temperature range
This setting defines the camera’s calibrated temperature range. Different camera models
have different temperature ranges. Select a range that suits your measurement situation.
