Page #36 background imageLoading...
Page #36 background image
11.10 Marking all areas above or below a set temperature
level
General
You can mark all areas above or below a set temperature level.
Procedure
Follow this procedure:
Push the left selection button (Menu).1
Use the navigation pad to select Measurement.2
Push the left selection button (Select).3
Use the navigation pad to select one of the following:
Detect above
Detect below
4
Push the left selection button (Select).5
To change the temperature level above or below which you want to mark
the areas, use the navigation pad.
6
26 Publ. No. T559580 Rev. a486 ENGLISH (EN) November 17, 2010
11 Using the camera

Table of Contents

Other manuals for FLIR i3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the FLIR i3 and is the answer not in the manual?

FLIR i3 Specifications

General IconGeneral
Infrared Resolution60 x 60 pixels
Thermal Sensitivity< 0.15°C
Temperature Range-20°C to +250°C
Field of View12.5° x 12.5°
FocusFixed
Battery Life5 hours
Operating Temperature-10°C to +50°C
Storage Temperature-40°C to +70°C
Display2.8 in color LCD
Weight0.34 kg
