CommentStructural drawing
Water has penetrated the concrete due to inade-
quately sized drop apron and has led to concrete
disintegration and corrosion of reinforcement.
SECURITY RISK!
10555003;a2
Water has penetrated the plaster and underlying
masonry at the point where the handrail is fastened
to the wall.
SECURITY RISK!
10554903;a2
60 Publ. No. T559580 Rev. a486 – ENGLISH (EN) – November 17, 2010
16 – Introduction to building thermography
