FLIR M100SERIES User Manual

2.1Documentinformation
Thisdocumentcontainsimportantinformationrelatedtotheinstallationandoperationof
yourFLIRproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthenecessaryequipment;
•installandconnectyourproductaspartofawidersystemofconnectedmarine
electronics;
•useyourproductalongwithanappropriatevideomonitor,joystickcontrolunit(JCU),
webbrowser,ormultifunctiondisplay(MFD).
•troubleshootproblemsandobtaintechnicalsupportifrequired.
ThisandotherFLIRproductdocumentsareavailabletodownloadinPDFformat
fromwww.ir.com/marine/support.
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
PartnumberNameDescription
E70432M132
(9Hz)
E70431M132
(30Hz)
Thermaltilt-only,
night-visionIPvideo
camera
E70354M232
(9Hz)
E70353M232
(30Hz)
Thermalpan-and-tilt,
night-visionIPvideo
camera
Systemkits
M100/M200–Seriesthermalcamerasaresuppliedindividually,oraspartofasystemkit.
Inadditiontothethermalcamera,systemkitsincludeajoystickcontrolunit(JCU)for
controllingthecamera.
Thecontentofeachsystemkitislistedbelow.Foralistoftheindividualpartssupplied
witheachcamera,seeM100/M200–Seriescamera.
Systemkit
partnumberDescription
Contents
(partnumbers)
T70333
M132CameraSystemKit
30Hz
•E70431:M132thermalcamera
30Hz(tiltonly)
•A80510:JCU-3controlunit
T70334
M132CameraSystemKit
9Hz
•E70432:M132thermalcamera
9Hz(tiltonly)
•A80510:JCU-3controlunit
T70335
M232CameraSystemKit
30Hz
•E70353:M232thermalcamera
30Hz(pan&tilt)
•A80510:JCU-3controlunit
T70336
M232CameraSystemKit
9Hz
•E70354:M232thermalcamera
9Hz(pan&tilt)
•A80510:JCU-3controlunit
16
