3.4T oolsrequired
Thefollowingtoolsarerequiredforinstallation.
ItemDescription
1.
Drill
2.10mmspanner
3.
Drillbitofappropriatesize*
4.
Jigsaw(onlyrequiredforJCUinstallation)
5.
Pozi-drivescrewdriver(onlyrequiredfor
JCUinstallation)
6.
Thread-lock
7.
50mm(2inch)Holesaw
Note:*Theappropriatedrillbitsizeisdependentonthethicknessandmaterial
ofthemountingsurface.
26
