JCU–3
TheJCU-3joystickcontrolunitisincludedincamerasystempacks,andisalso
availabletopurchaseasaseparateaccessory.Theunitissuppliedwithbotha
portrait-orientedkeypad(tted),andalandscape-orientedkeypad.
Forinformationonotheraccessories,seeChapter10Sparesandaccessories.
Note:Y ourM100/M200-Seriesthermalcameraisalsocompatiblewiththefollowing
joystickcontrolunits,providedwithotherFLIRandRaymarinecamerasystems:
•JCU-1(partno.500-0385-00)—joystickcontrolunitforFLIRM-Seriesand
RaymarineT-Seriescameras
•JCU-2(partno.500-0398-00)—joystickcontrolunitforFLIRM400-Series,
MV-SeriesandMU-Seriescameras
Partssupplied
Thepartssuppliedwiththekeypadareshownbelow.
1.JCU-3keypad
2.Landscapekeypadmat
3.Portraitkeypadmat(suppliedttedtotheunit)
4.Mountinggasket
5.4xmountingxings
6.Documentationpack
7.Rightangledpowercable2m(6.6ft.)
8.RayNetnetworkcable2m(6.6ft.)
