Using the System
11
2. Adjust the Hue, Brightness, Contrast, and Saturation settings that the camera will
use. To enable custom Gain controls, check Gain and use the slider to configure the
gain level.
3. Click OK to save changes.
11.4 Using the Navigation Bar
The Navigation Bar gives quick access to certain functions and menus.
To open the Navigation bar:
• Left click on the screen to open the Navigation Bar. The Navigation Bar has the follow-
ing options:
1. Main Menu.
2. Collapse.
3. Select display layout.
4. Sequence: Click to start/stop sequence mode.
5. PTZ: Click to open PTZ controls.
6. Camera: Click to open camera image settings.
7. Search: Search and playback recorded video. See 19.4 Playback, page 88.
8. Alarm Status: View alarms in progress. See 17.2.4 Alarm Status, page 49.
9. Channel Info: Click to access status information about connected cameras.
10. Network: Configure network settings for your system. See 17.3.1 Network, page 53.
11. HDD Manager: Manage hard drives connected to the system. See 17.3.18 Format-
ting the Hard Drive, page 66.
12. USB Manager: Click to access options for connected USB thumb drives (not in-
cluded). You can backup video, logs, or system configurations and install firmware
upgrades.
13. System Update: Click to check for firmware upgrades. Your system must be con-
nected to the Internet to check for firmware upgrades.
11.5 Using the Camera Toolbar
The Camera Toolbar is used to perform actions on a specific channel.
#LX400051; r. 1.0/23100/23101; en-US
