1 PT-Series HD Camera Installation
Other Serial Communication Parameters: The tables below defines the switch locations, bit
numbering and on/off settings used in controlling the other serial communication parameters.
Table 1-3: Dip Switch Settings—SW103
Settings Description
Baud rate: This is the baud rate of the system user serial
port. The available values are 2400, 4800, 9600, 19200
kbaud.
Bit 1 Bit 2
OFF OFF
2400
ON OFF
4800
OFF ON
9600
ON ON
19200
Camera Control Protocol: This is the communication
protocol selected for the system when operating over the
serial port. The available protocols are Pelco-D and
Bosch.
Bit 3 Bit 4
OFF OFF
Pelco-D
ON OFF
NA
OFF ON
Bosch
ON ON
NA
Serial Communication Standard: This determines the
electrical interface selected for the user serial port. The
available settings are RS422 and RS232.
Bit 5 Bit 6
OFF OFF
NA
ON OFF
RS422
OFF ON
RS232
ON ON
N/A
Not Used
Bit 7 Bit 8
X X
X X
X X
X X
Software Override DIP Switch: This setting determines
whether the system will use software settings for
configuration or if the dip switch settings will override the
software settings. Default is Off.
Bit 9
OFF
Software select
ON
Hardware select
Not Used
Bit 10
X
