FLIR PT-606Z HD

427-0075-01-12 Version 110 November 2017 9
1 PT-Series HD Camera Installation
1.5.3 Installation of Camera and Galvanic Isolation Kit
Important Safeguards and Warnings
• Installation and servicing should be done by qualified installation and service personnel only.
• Installation should be done according to all local and national electrical and mechanical codes,
using only approved materials.
Warning!
• Once the mounting location has been selected, verify both sides of the mounting surface are
accessible and free of utility service lines or other obstructions.
• Use stainless steel hardware to fasten mounts to outdoor surfaces.
• Use a thread locking compound such as Loctite 242 or equivalent with all metal to metal threaded
connections.
• To prevent damage from water leakage when installing outdoors, apply sealant around the bolt
holes between the mount and the mounting surface.
Caution!
Step 1 Determine the correct positioning of the isolation plate (See Figure 1-3 on page 10).
Step 2 Place the isolation plate and the camera on the mounting structure aligning the bolt holes or
studs.
Step 3 Install nylon shoulder washers (4x) or nylon flat washers (4x) onto camera base.
If using nylon flat washers, apply a generous coat of Tef-Gel filling all gaps and voids.
Before drilling into walls or ceilings for mounting the camera, verify that areas behind these positions
do not contain electrical or other utility service lines. Serious injury or death may result from failure
to heed this warning.
Following this procedure is critical to maintaining the warranty on your PT-Series HD product.
Failure to follow these instructions can potentially void the camera warranty.
Table 1-1: Kit Contents
Description Qty
Isolation plate
1
M8 nylon flat washer
a
M8 nylon shoulder washer
a. Use the alternate nylon flat washers and Tef-Gel lubricant on fasteners for PT-Series HD camera bases
with mounting holes that are too small to accept the shoulder washers. A syringe of Tef-Gel will be supplied
in the mounting kit when the nylon flat washer is required.
6
6
Two extra pieces of each attaching part are
supplied in the kit.
M8 split washer, S.S.
6
M8 washer, S.S.
6
Tef-Gel TG .25, 3 cc syringe
a
optional
