1 PT-Series HD Camera Installation
1.7 PT-Series HD Camera Specifications
Thermal Camera
Array Format 640 x 512 (17 µm pixel pitch)
Detector Type Long-Life, uncooled VOx microbolometer
Spectral Range 7.5 to 13.5 µm
Effective Resolution 307,200 (NTSC), 327,680 (PAL)
Pixel Pitch 17 µm
Lens Athermalized, focus-free
Optical Zoom Continuous to 4x – PT-606Z HD only
E-Zoom Continuous E-Zoom to 4x
Image Frequency 25 Hz / 30 Hz; 8.33 Hz video standard PAL/NTSC—switchable from
Video web page.
Field Of View (Focal Length) for
available 640 x 512 camera lens
configurations.
PT-606Z HD - 24° HFoV to 6° HFoV
(26 mm to 105 mm zoom), f/1.6
PT-608 HD - 8.6° × 6.6° (75 mm), f/1.1
PT-612 HD - 12° × 10° (50 mm), f/1.2
PT-617 HD - 17° × 14° (35 mm), f/1.1
PT-625 HD - 25° × 18° (25 mm), f/1.1
PT-644 HD - 44° × 36° (13 mm), f/1.0
Thermal Camera – PT-602CZ HD
Array Format 640 × 480 (NTSC), 640 x 512 (PAL)
Detector Type Cooled MWIR
Spectral Range 3 µm to 5 µm
Thermal Sensitivity <30 mK @ 25 °C
Effective Resolution 307,200 (NTSC), 327,680 (PAL)
Field Of View WFOV: 28° x 22.4° (PAL) 28° x 21° (NTSC)
NFOV: 2° x 1.6° (PAL) 2° x 1.5° (NTSC)
Optical zoom Continuous to 14x
E-Zoom Continuous E-Zoom to 4x
Image Frequency 25 Hz / 30 Hz video, PAL/NTSC—switchable from Video web page.
Visible Camera Specifications
Detector Type 1/2.8-type Exmor R CMOS
Effective resolution 2,130,000 pixels
Field Of View Field of view: 63.7° HFoV to 2.3° HFoV
Lens 30x optical zoom, 12x digital zoom
4.3 mm (wide) to 129.0 mm (narrow), F1.6 to F4.7
Outputs
Composite Video NTSC or PAL Standard—switchable from Video web page.
Video Streaming H.264 or MJPEG
Control
Ethernet Complies with IEEE 802.3u, 10BASE-T/100BASE-TX
Network Interfaces Camera Web Server, ONVIF 2.0 Profile S, FLIR SDK, FLIR CGI Library
Serial RS-232/-422 (Pelco D, Bosch)
External Analytics Compatible yes
