1 PT-Series HD Camera Installation
Pan/Tilt
Pan Angle/Speed Continuous 360°; 0.1° to 60°/sec
Tilt Angle/Speed +90° to -90°; 0.1° to 30°/sec
Programmable presets 128
Ge n e r a l
Weight < 40 lb (18 kg)
Dimensions (L,W,H) 13.7” × 18.4” × 13” (348 mm x 467 mm x 330 mm)
Power
Input Voltage 24 Vac (21-30 Vac); 24 Vdc (21-30 Vdc)
Power Consumption
a
24 Vac: 85 VA max w/o heaters; 215 VA with heaters
24 Vdc: 65 W max w/o heaters; 195 W with heaters
Environmental
IP rating (dust and water ingress) IP66
Operating temperature range -50 °C to 70 °C (-58 °F to 158 °F) continuous
-40 °C to 70 °C (-40 °F to 158 °F) cold start
Storage Temperature range -55 °C to 85 °C (-67 °F to 185 °F)
Humidity 0-95% relative
Endurance IEC 60068-2-64 and MIL-STD-810G,
Method 514.6, Procedure 1b
Operational Mechanical Shock IEC 60068-2-27, 10 g shock, 11 ms half-sine profile
De-Icing MIL-STD-810G, Method 521.2; 6 mm ice, 120 min @ -10 °C
Approvals CE Marked per EN 61000-6-4:2007, IEC 61000-3-
3:1995+A1:2001+A2:2005, EN 61000-3-2:2006 and EN 50130-
4:1996+A1-1998+A2-2003
FCC CFR Title 47, Part 15 Subpart B, Class A
a. Power consumption is independent of the input voltage when the heater is off. The power drawn by the heaters in-
creases with the input voltage to a maximum at 30 Volts.
