427-0075-01-12 Version 110 November 2017 30
2 Basic Operation and Configuration
Pan and Tilt
The azimuth and elevation angles are measured in degrees. The elevation angle is measured from
horizontal; negative values are down, positive values are up. The Azimuth angle is measured from the
front of the pan/tilt unit; negative values are counter-clockwise, positive values are clockwise.
Surveillance > Scan List
To move the camera:
enter coordinates,
click Go to
Current camera
coordinates and
pan/tilt mode
Click Set
select Preset ID
position camera,
To setup Presets:
