Flo CoRe+ - Dual back-to-back charging station installation

CoRe+
TM
Cable management system and pedestal installation guide
10
Dual back-to-back charging
station installation
IF THE PEDESTAL IS NOT PRE-DRILLED, USE THE FOLLOWING DRILLING TEMPLATES:
Top Drilling template
MEC-CST-00280
Bottom Drilling template
MEC-CST-00278
Included material Qty
Cable management system columns and cable clamp
2
Top mounting brackets
2
Round spacing shims
2
Rectangular spacing shims
2
Self-adhesive rubber band
2
¼-20 screws (1’’) (for pre-drilled pedestal) 6
Self-drilling screws (1’’) (for pedestal with no holes) 6
Drilling template
1
Drilling template (bottom pedestal)
1
