STRADA GENERATION3 – S5 - INSTALLATION MANUAL
41/66
D. Install the formwork (1) into the base (2).
Respect the positioning: the front of the base must be placed in a way to respect the
orientation of the terminal to be installed. The rounded edges (2) correspond to the rear
of the terminal. The notch (1), corresponding to the front of the terminal, must always be
upward.
Check that the water drain holes (3) of the base are not clogged.
E. Fill the hole with concrete (minimum quality C25/30).
F. Lower the base (3) with its formwork (2) to the desired height by pushing the
anchoring rods down into the concrete.
G. Check the horizontal alignment of the base with a spirit level (4).
terminal
